E-2224 - back-side photo

E-2224 - back-side photo
E-2224, back view
Detailed specifications →Front photo →
CPU-Info Benchmark

Intel Xeon E-2224 ranking

A calculated comparison score based on processor specifications.

Points116 300
Rank221
Compare nine processors

Processor contact side

This photograph shows the back of the E-2224 processor, including its contact side and substrate components. Detailed technical specifications are available on the model page.

Key specifications

ModelE-2224
SocketLGA1151
Intended useserver computer
CPU-Info Benchmark

Compare nearby processors

Four models above, the selected processor, and four below. Points are calculated from specifications, not measured on a particular PC.

Full ranking
Other modelsSelected processor
217E-2224G117 500
218i5-8600T117 250
219E3-1240 V6116 660
220E3-1245 V6116 660
221E-2224116 300
222i5-9400T116 000
223i3-9320114 900
224i3-9300113 900
225i5-8500T113 350

Scores and positions may change as the CPU-Info Benchmark catalog grows.

Intel Xeon E-2224: back-side photograph and contacts

Examining the contact side

The back-view photograph of Intel Xeon E-2224 shows the processor substrate and its electrical contact area. Package and contact designs vary by processor family. Visual inspection can reveal obvious contamination or mechanical damage, but it cannot confirm that every connection works correctly or that the processor will initialize in a computer.

Why the socket matters

Specified socket: the socket listed in the specification table. Processors from different Intel families can share similar exterior dimensions without being interchangeable. Always compare the board socket, keying, supported CPU list and BIOS requirements. Do not attempt to install a processor using force when alignment or compatibility is uncertain.

Safe inspection before installation

Before fitting E-2224, inspect the motherboard socket and the processor contact surfaces under good lighting. Avoid touching exposed contacts unnecessarily. Check for contamination, damaged pads, bent socket contacts and signs of prior repairs. Follow suitable electrostatic-discharge precautions when handling loose PC components.

How contacts relate to CPU specifications

The electrical interface connects the processor to motherboard power, memory and communication signals. Published model specifications tell you which platform to use; the photograph only illustrates the package and its physical connection surface.

Using the photograph for comparison

Compare this image with the front-side photograph and the detailed specification table for E-2224. The reference also provides CPU-Info Benchmark scores and neighboring processors. These calculated results help organize model comparisons but do not constitute an on-device performance test or a diagnosis of a processor's condition.
